Bar Manifolds are enhanced to maximize performance while accommodating the highest number of standard options in a more uniform and easier-to-install package.
TappingPlates
Tapping Plates
Tapping Plates are sandwich adapters designed to provide a means to easily take pressure readings from the work ports.
SubPlates
Sub Plates
Subplates are designed to provide a means to connect a single solenoid valve to field piping either on the power unit or near the actuator.
SubPlatesWCircuit
Sub Plates With Circuits
Similar to the Subplates; Subplates with relief from P to T provides an integral system relief cavity to minimize piping.
CoverPlate
Cover Plates
Cover Plates are used in place of directional valves to either completely block off a bar manifold station, or to provide a means of flushing a manifold as determined by the internal port connections chosen.
Headers
Headers
Headers provide a common through port for multiple inlet or outlet ports at each station to be neatly connected together - providing support to the piping station.
Junctions
Junctions
Junctions offer termination points to join individual lines in order to change direction or combine/split flow with other lines at each station - providing support to the piping station.
DINBodies
DIN Bodies
Din Bodies are designed for standard two-port slip-in cartridges. The bodies are designed to offer the maximum in flexibility in circuit applications.
ValveAdapters
Valve Adapters
Valve Adapters are transition plates designed to provide a means to mount different valve types to existing manifold interfaces.
